Clean Room Design Solutions

For over 20 years, our experienced and knowledgeable staff has provided innovative solutions to the cleanroom industry including; modular cleanrooms, cleanroom furniture, equipment, and consumables. Our partnership with the Servicor line, with over 25 years of design and fabrication experience enables us to deliver the industry’s highest quality and cost-effective design. Our cleanrooms meet a wide range of cleanliness levels; from Class 100 to 100,000 as well as USP 797 capabilities.

All cleanrooms are available in either hardwall or softwall panels, in clear acrylic or static-dissipative PVC. Unlike any other cleanroom, their unique Uni-Grid ceiling system can incorporate a structurally designed truss system and span up to 50 ‘ without the need for additional down posts.

  • Best Looking Finished Clean Room: steel frame, polyurethane powder coating
  • Hook-up & Fit-up pentrations easier
  • Most Durable, Heavy Duty Room available
  • Class 100 to 100,000
  • When choosing a Hardwall Cleanroom you have chosen the most visual, durable, and heavy duty room on the market today
  • Exclusive Uni-Grid load-bearing, walkable ceiling system allows for easy maintenances and interchange of lights, tiles and HEPA filters
  • Available in an unlimited number of sizes and configurations using standard components
  • Truly modular construction, featuring full panels and no sub assemblies, provides maximum flexibility to accommodate new processes and equipment
  • Fastest to install, simple to relocate, and pre-engineered to meet your demanding schedule

STRUCTURAL INTEGRITY

Servicor Hardwall cleanrooms stand out as the most structurally rigid available anywhere in the industry. Formed from cold-rolled tubular steel, each frame is incredibly robust and highly durable. Together with any of the available hardwall inset panels and our exclusive ceiling system, the frames compose a room which can be seismically rated and will endure punishment from outside and within.

CLEANLINESS AND DURABILITY

All Servicor frames and ceiling grids are powder coated with a polyurethane material then baked at 450 degrees to ensure truly non-outgassing components. Unlike epoxy, which is an outgassing product, or unbaked powder coatings, the Servicor process provides an extremely hard-shell finish that will withstand frequent cleansing and will not contaminate your process. The result is a beautiful, consistent finish on a room that looks simple even though it meets detailed requirements.

UNIQUE AND INTELLIGENT DESIGN

Servicor’s exclusive Uni-Grid ceiling system is fully welded to form a structurally superior and unified ceiling grid. It is then powder-coated and fitted with closed-cell gasketing that creates a tight seal with all drop-in components. Each fully loaded Uni-Grid is self-supporting and completely walkable, allowing for simple exchange of the 2′x4′ lights, tiles and Fan Filter Units. Servicor’s CleanSeal panel inset fastening system mounts flush to the steel frame to create a “ledge-less” room interior. The result is an easyto-clean room with reduced bio-burden and a positive seal to protect your process form particulates.

For more detailed specific information please contact our account managers to help you determine what type of room you need for your specific environment.

Servicor Stretchwall Cleanrooms

Servicor Stretchwall Cleanroom

  • Class 100 to Class 100,000
  • All equipment is easily accessible, for maintenance or repair, because of the heavy duty UniLock (velcro) walls
  • Less expensive option then the Hardwall Cleanroom, but with the same overall appearance
  • When the air is fully functional, room shows a ‘bubble-like’ appearance
  • When choosing a Stretchwall Cleanroom you have chosen a quality cleanroom that allows easy accessibility from anywhere outside of the actual room.. All rooms are interchangeable and work with all of our available components.
  • Economical alternative to Hardwall panel construction
  • Exclusive Uni-Grid load-bearing, walkable ceiling system allows for easy maintenance and interchange of lights, tiles and HEPA filters
  • Available in an unlimited number of sizes and configurations using highquality standard components
  • Truly modular construction provides maximum flexibility to accommodate new processes and equipment
  • Fast to install, simple to relocate, and pre-engineered to meet your demanding schedule

For more detailed specific information please call one of account managers to help you determine what type of room you need for your specific environment.

Servicor Softwall Cleanroom

  • Sturdier, more rigid frames with a 3″x3″ downpost
  • Pre-tagged and packaged for easy assembly
  • Materials are easily replaced or modified for future growth or relocation
  • Most affordable room of the series
  • Class 100 to 100,000
  • When choosing a Softwall Cleanroom you have chosen the best looking, most affordable room on the market. All rooms are interchangeable and work with all of our available components.
  • Most affordable clean enclosure option isolate modestly-sized areas
  • The lightest and most portable cleanroom available, optional casters allow complete mobility
  • Uni-Grid load-bearing, walkable ceiling system
  • Standardized components and modular construction provide maximum
  • flexibility to accommodate new processes and equipment
  • Fast to install, simple to relocate, and pre-engineered to meet your demanding schedule

For more detailed specific information please contact one of our Account Managers to help you determine what type of room you need for your specific environment.

Cleanroom Walls and Ceilings

Cleanpak’s Servicor walls and ceilings are essential to your complete cleanroom package. Each of our frames are constructed with tubular steel and finished with a powder coating that withstands frequent and stringent cleansings.

Our Unigrid Ceiling System is unbeatable with is load bearing abilities and its complete modular capabilities.

For more detailed specific information please contact one of our Account Managers to help you determine what type of room you need for your specific environment.

Grid Units

  • Fully welded steel grid units
  • Load-bearing and walkable
  • Truly modular for easy room expansion
  • Guaranteed leak-free at T-bar intersections
  • Spans up to 20′ without additional downposts

For more detailed specific information please contact one of our Account Managers to help you determine what type of room you need for your specific environment.

Doors & Jambs

  • Custom designed specifically to work with the Servicor frame system
  • Welded, Steel Frame
  • Heavy Duty, Durable
  • Welded Hinges

For more detailed specific information please contact one of our Account Managers to help you determine what type of room you need for your specific environment.

Standard Frames

  • Pre-Assembled for tilt-up construction
  • Floor Supported
  • Interchangeable & Expandable
  • High load bearing ceiling

For more detailed specific information please contact one of our Account Managers to help you determine what type of room you need for your specific environment.
